Description
The EMT-400 Radial Drilling Machine from Excellent Machines & Tools is engineered for precision drilling, boring, reaming, and tapping operations in workshops and industrial manufacturing environments. Its radial arm construction allows easy positioning of the spindle over large workpieces, improving productivity and machining efficiency.
Available in drilling capacities of 25 mm, 32 mm, and 40 mm, the machine offers excellent versatility for different industrial applications. The sturdy pillar and arm structure ensure stability during operation, while the adjustable arm movement enables accurate drilling at various positions.
Built for durability and consistent performance, the EMT-400 is suitable for fabrication shops, engineering workshops, machine shops, and manufacturing industries requiring dependable drilling solutions.
Key Features
- Heavy-duty radial arm construction
- Multiple drilling capacity options
- Smooth arm movement and positioning
- High operational accuracy
- Suitable for large workpieces
- Durable industrial design
- Reliable workshop and production performance
Technical Specifications
| Description | 25 mm | 32 mm | 40 mm |
|---|---|---|---|
| Drilling Capacity in Steel | 25 mm | 32 mm | 40 mm |
| Distance of Spindle Centre to Column (Max.) | 500 mm | 650 mm | 925 mm |
| Distance of Spindle Centre to Column (Min.) | 175 mm | 200 mm | 250 mm |
| Distance of Spindle Nose to Base (Max.) | 550 mm | 680 mm | 950 mm |
| Distance of Spindle Nose to Base (Min.) | 125 mm | 150 mm | 250 mm |
| Pillar Diameter | 140 mm | 175 mm | 200 mm |
| Travel of Arm on Column (Vertical) | 675 mm | 675 mm | 900 mm |
| Travel of Arm on Column (Horizontal) | 600 mm | 600 mm | 900 mm |
Applications
- Drilling Operations
- Reaming Operations
- Tapping Operations
- Fabrication Workshops
- Engineering Industries
- Machine Shops
- Manufacturing Units
