Description
The EMT-400 Radial Drilling Machine from Excellent Machines & Tools is engineered for precision drilling applications in workshops, fabrication units, and industrial manufacturing facilities. The machine is equipped with a rigid column structure and adjustable radial arm, allowing efficient drilling on large and heavy workpieces.
Designed for durability and accuracy, the EMT-400 is available in multiple drilling capacities and offers flexible spindle positioning for a wide range of machining requirements. The machine incorporates anti-deflection support, press brake tooling compatibility, and sample tool adaptability for improved operational efficiency.
Features
- Anti-Deflection System
- Press Brake Tooling Support
- Sample Tool Compatibility
- Heavy-Duty Construction
- Precision Drilling Performance
- Industrial Grade Design
Technical Specifications
| Description | 25 mm | 32 mm | 40 mm | 50 mm |
|---|---|---|---|---|
| Drilling Capacity in Steel | 25 | 32 | 40 | 50 |
| Spindle Centre to Column DLS Min & Max | 175-500 | 200-650 | 250-925 | 400-1100 |
| Spindle Nose to Base DLS Min & Max | 125-550 | 150-680 | 250-950 | 310-1125 |
| Pillar Diameter | 140 | 175 | 200 | 225 |
| Arm Travel to Column (Vertical & Horizontal) | 675, 600 | 675, 600 | 900, 900 | 1275, 1175 |
Applications
- Steel Drilling
- Fabrication Workshops
- Engineering Industries
- Machine Shops
- Industrial Manufacturing
- Maintenance Workshops
